St Express Features and Benefits Include: Room for Four: Forward Facing, Four - Passenger Seating on the ST Express Provides Plenty of Space for Everyone. Smooth Ride: The ST Express Features 23 - inch Terra Trac Tires for a Comfortable Ride over any Terrain. Attractive Diamond - Wheel Rims add an Element of Style. Versatillity: Powerful Gas or 48 - Volt Electric Engine, Three - Bar Steel Brush Guard and Custom Two- Tone Seats in Black/Red or White/Viper Blue. Best in Class Hauling Capability: With a 800lb Payload and the Option of a Stake - Side Bed, Roto - Molded Bed or a Versatile Flip-Flop Seat that Folds Down to Increase Storage Space, the ST Express Offers Unparalleled Hauling Capability. From Groceries to Gardeding Tools, the Express can Carry the Load. Overall Length 138.0 in (351 cm) Frame Welded tubular steel with DuraShield™ powder coating Seating Capacity 4-person (6 Person with optional rear seat kit) Steering Self-compensating reduction rack and pinion Power Source 4-cycle, 24.5 cu in (401 cc) low emissions
Overall Width 46.5 in (119 cm)
Overall Height
(no canopy) 52.5 in (133.5 cm) (top of steering wheel)
Overall Height
(with canopy) 76.0 in (193 cm) (top of sun canopy)
Wheel Base 95.0 in (241 cm)
Front Wheel Track 37.5 in (95 cm)
Rear Wheel Track 38.5 in (98 cm)
Ground Clearance
(at differential) 7.0 in (18 cm)
Front Body & Finish Injection-molded Geloy XTW
Rear Body & Finish Fiberglass with Gelcoat and Injection-molded TPO (Thermoplastic Olefin)
Standard Color Electric Blue/White or Black/Flame Red
Dry Weight 960 lb (440 kg)
Curb Weight 1010 lb (460 kg)
Bed Load Capacity 250 lb (110 kg)
Vehicle Load Capacity 1200 lb (540 kg)
Outside Clearance Circle 25.5 ft (7.8 m)
Forward Ground Speed 16.0 mph ± 0.5 mph (25.7 kph ± 0.8 kph)
Reverse Ground Speed 12.0 mph ± 0.5 mph (19.3.0 kph ± 0.8 kph)
Front Suspension Leaf springs with hydraulic shock absorbers
Rear Suspension Leaf springs with hydraulic shock absorbers
Service Brake Dual rear wheel mechanical self-adjusting drum brakes
Parking Brake Self-compensating single-point engagement
Front Tires Terra Trac 23 x 10.5 -12 on Diamond Alloy Wheel
Rear Tires Terra Trac 23 x 10.5 -12 on Diamond Alloy Wheel
Valve Train Single cylinder OHV
Horsepower (kW) 13 hp (9.7 kW)
Electric System Starter/generator, solid state regulator
Batteries (qty/type) One 12-volt, maintenance-free
Air Cleaner Industrial rated dry filter
Lubrication Pressurized oil system
Oil Filter Spin on
Cooling System Air cooled
Fuel Capacity 5.8 gallons (22.0 L)
Drive Train Automatic, continuously variable transmission (CVT)
Transaxle Differential with helical gears
Gear Selection Forward-reverse
Rear Axle Ratio 11.42:1 (forward) 15.78:1 (reverse)
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
